Plug-and-pull mode |
Push-pull self-locking type |
|
Operating temperature |
-55°C-+125°C |
|
Salt spray |
5%NaCI (neutral) in fog 96h |
|
Vibration |
10Hz-2000Hz, 147m/s2, instantaneous break ≤1us |
|
strike |
980m/s2 Instantaneous break ≤1us |
|
Mechanical life |
5000 times |
|
Dielectric withstand voltage |
500V（DC） |
|
Insulation resistance |
≥3000MΩ |
|
Contact resistance |
≤12.5mΩ（Φ0.7） |
|
Shielding property |
75dB(100MHz) |
|
Head seat with sealing |
1.5m water depth 25h no seepage (tail need to be sealed protection treatment) |
|
The separation of the plug (recommended) from the socket |
≥0.2N |
|
Plug (recommended) and socket insertion force |
≤3.34N |
|
Materials and coatings |
The jacks are gold-plated with tin bronze, the pins are gold-plated with brass, the shell is brass plated with black chrome, and the insulators are PPS |
|
Waterproof grade |
IP68 |
