Push-pull 1P series
The Push‑pull 1P series are lightweight plastic circular push‑pull self‑latching connectors, widely adopted for medical equipment, test‑measurement instruments, portable electronic devices and industrial signal interconnection. Featuring intuitive push‑to‑mate and pull‑to‑disconnect operation, the built‑in self‑lock mechanism ensures stable anti‑vibration connection, preventing accidental disconnection caused by cable tension. This portfolio covers panel‑mount receptacles, cable‑mount straight plugs, with multi‑color coded backshell options and multiple keying configurations to avoid mis‑mating. Gold‑plated contacts deliver reliable low‑resistance signal transmission, supporting frequent plug‑and‑unplug cycles. RoHS‑compliant thermoplastic housing provides compact size and excellent cost‑performance for space‑constrained device integration.
Main Product Types
1PK‑A‑05‑N‑L‑N
Panel‑mount Receptacle (Rear‑mount)
Back‑panel locking receptacle with double‑nut fastening design for cabinet / equipment panel installation. Male gold‑plated pin contacts. Black plastic housing, compact threaded mounting structure for secure panel fixation. Suited for fixed‑side interface of medical devices and portable instruments.
1PF‑A‑05‑N‑A‑C‑XX‑N
Cable Plug, Black Housing
Free cable plug with black grip sleeve, marked with mating / release directional arrows. Push‑pull latching structure, field‑terminable for customer‑prepared cables. Matches with corresponding 1PK panel receptacles for quick field assembly.
1PR‑N‑XX‑GLC‑XX‑W
Cable Plug, White Backshell
Straight free plug assembly, grey main housing with white twist‑grip cable strain‑relief backshell. Multi‑pin contact configurations optional; colour‑coded backshell prevents cross‑mating in multi‑connector systems.
1PR‑N‑XX‑GLC‑XX‑J
Cable Plug, Yellow Backshell
Grey main body paired with yellow coded backshell. Push‑pull self‑locking, supports solder termination. Colour coding helps visual identification among multiple interconnection ports on one device.
1PR‑N‑XX‑GLC‑XX‑N
Cable Plug, Black Backshell
General‑purpose free plug with black strain‑relief backshell. Standard configuration for most signal‑cable assemblies, compatible with matched panel‑mount sockets.
1PR‑A‑XX‑GLC‑XX‑G
Cable Plug, Light‑Grey Backshell
Full light‑grey monochromatic housing & backshell, neutral appearance for medical and lab instrument housings. Multiple key code options available.
1PR‑N‑XX‑GLC‑XX‑G
Cable Plug, Grey Knurled Backshell
Knurled textured grey backshell for improved hand‑grip when operating plug‑pull cycles. Optimised for frequent manual connection‑disconnection scenarios.
1PR‑N‑XX‑GLC‑XX‑V
Cable Plug, Green Backshell
Grey plug body with green coded backshell, visual identification for differentiated signal channels within multi‑connector systems.
1PR‑N‑XX‑GLC‑XX‑R
Cable Plug, Red Backshell
Grey housing with red coded backshell. Distinctive colour marking for critical signal loops, avoiding wrong‑port mating on equipment panels.
Key Features
- Push‑pull self‑locking: Push to lock, pull sleeve to release; resists accidental cable‑pull disconnection
- Multi‑colour coded backshell & mechanical keying options to eliminate mis‑mating
- Gold‑plated copper contacts for stable low‑noise signal transmission
- Light‑weight high‑performance plastic housing; RoHS compliant
- Product portfolio includes rear‑mount panel receptacles and field‑assemblable cable plugs
- Compact footprint, ideal for portable devices, medical monitoring, laboratory test gear
- Supports custom contact pin counts, key codes and cable assembly service
Typical Applications
Medical monitoring equipment, portable analytical instruments, test‑and‑measurement devices, handheld industrial equipment, small‑size signal interconnection modules.
