No.of contacts OF: 2,3,4,5,6,7,9
No.of contacts 1F: 2,3,4,5,6,7,8,10,12,14
| Locking type | self-latching |
| Working temperature | -55~+250°C |
| Shielding capability | 75dB(10MHz), 40dB(1GHz) |
| Vibration | 15g(10Hz-2000Hz) |
| Salt spray test | 96Hrs |
| life cycle | 5000 |
| shock resistance | 100g,60ms |
| IP grade | IP68 |
| Max humidity | @60°,95% |
Descriptions:
• Easy blind mating in difficult-to-reach places
• Less panel space required
• Robotic mating and demating possible
• Security of the push-pull self-latching system
• Security of push pull self latching system
• Keying with halfshells
• High packing density for space saving
• IP rating: IP50,IP68
• Multiple sizes
0F - 2,3,4,5,7 poles
1F - 2,3,4,5,6,7,12 poles
Applications:
Medical Electronics
Test and Laboratory,
Measurement Instrumentation
Data and Telecom Systems
Audio and Video Applications
Military and Aerospace
Industry Control
